OBDSTAR Adds Hyundai IONIQ5 Palisade K5 2023- IMMO

 OBDSTAR X300 DP Plus and X300 Classic G3 released new Hyundai IMMO software v41.56.



Add blade, remote and proximity key programming for following models
Hyundai Australia I30 2023-
Hyundai North America IONIQ 5 (NE EV) 2023-
Hyundai South America IONIQ 5 (NE EV) 2023-
Hyundai Aisa Korea Palisade (LX2) 2023-
Hyundai Aisa OtherPalisade (LX2) 2023-
Kia Aisa Carnival (KA4) 2023-
Kia Europe Carnival (KA4) 2023-
Kia Europe K5 (DL3A) 2023-
Kia South America K5 (DL3A) 2023-

Add read pin code proximity 4A- BAYON (BC3)

OBDSTAR G3 Update Volvo ABS and ECM Learning

 OBDSTAR X300 Classic G3 updated Volvo ECU software V30.00.

Add learn ABS function and learn ECM function for Volvo X60, XC80, S80, V40 XC70 vehicles.

Highlights Added 8

Add Learn ABS function for below models:

• VOLVO 60 BOSCH EDC16 2007-

• VOLVO 60 BOSCH EDC17 2007-

• VOLVO 60 BOSCH SID807EVO 2007-

• VOLVO 60 DENSO 2013-

• VOLVO 70 BOSCH EDC16 2007-

• VOLVO 70 BOSCH EDC17 2007-

• VOLVO 70 BOSCH SID807EVO 2007-

• VOLVO 70 DENSO 2013-

• VOLVO 80 BOSCH EDC16 2007-

• VOLVO 80 BOSCH EDC17 2007-

• VOLVO 80 BOSCH SID807EVO 2007-

• VOLVO 80 DENSO 2013-

• VOLVO S80 BOSCH SID206

• VOLVO V40 BOSCH EDC17 2013-

• VOLVO V40 BOSCH SID807EVO 2013-

• VOLVO V40 DENSO 2013-

Add Learn ECM function for below models:

• VOLVO 60 BOSCH EDC16 2007-

• VOLVO 60 BOSCH EDC17 2007-

• VOLVO 60 BOSCH SID807EVO 2007-

• VOLVO 60 DENSO 2015-2018

• VOLVO 70 BOSCH EDC16 2007-

• VOLVO 70 BOSCH EDC17 2007-

• VOLVO 70 BOSCH SID807EVO 2007-

• VOLVO 70 DENSO 2015-2018

• VOLVO 80 BOSCH EDC16 2007-

• VOLVO 80 BOSCH EDC17 2007-

• VOLVO 80 BOSCH SID807EVO 2007-

• VOLVO 80 DENSO 2015-2018

• VOLVO V40 BOSCH EDC17 2013-

• VOLVO V40 BOSCH SID807EVO 2013-

• VOLVO V40 DENSO 2013-2015

• VOLVO V40 DENSO 2015-2018

OBDSTAR DC706 Adds VAG MG1CS001 ECUs

OBDSTAR DC706 and X300 Classic G3 update new ECU flasher software V30.70 on April 30th, 2024.

*G3 need to activate ECU flasher license to have these updates.

Add Read/Write INT flash, ReadA/Vrite I NT eeprom functions for below models:

• ALFA ROMEO BOSCH EDC17C69 TC1793

• ALFA ROMEO BOSCH MED17.3.3 TC1793

• AUDI BOSCH MG1CS001 SPC5777

• CITROEN BOSCH MEV17.4.2 TC1767

• DAEWOO SIEMENS/KEMSCO D3 29F200BT

• DODGE BOSCH DCU17HD01 TC1766

• FIAT BOSCH EDC17C69 TC1793

• FODAY BOSCH EDC17C53 TCI 767

• GENESIS BOSCH EDC17C57 TC1793

• GENESIS BOSCH MED17.9.30 TC1793S

• GREATWALL BOSCH EDC17C53 TC1767

• HONDA BOSCH EDC17C58 TC1793

• HYUNDAI BOSCH EDC17C53 TC1767

• HYUNDAI BOSCH EDC17C57 TC1793

• HYUNDAI BOSCH EDC17CP62 TC1793S

• HYUNDAI BOSCH MED17.9.30 TC1793S

• HYUNDAI CONTINENTAL SIM2K-240 TC1767+TC1738

• HYUNDAI CONTINENTAL SIM2K-241 TC1767+TC1738

• HYUNDAI KEFICO MEDG17.9.8 R5F72549R+TC1767

• HYUNDAI KEFICO MEG17.9.8 R5F72549R+TC1767

• ISUZU BOSCH EDC17C83 TC1793

• IVECO BOSCH EDC17C69 TC1793

• JAGUAR BOSCH MED17.8.32 TC1793

• JEEP BOSCH EDC17C69 TC1793

• KIA BOSCH EDC17C53 TC1767

• KIA BOSCH EDC17CP62 TC1793S

• KIA BOSCH MED17.9.30 TC1793S

• KIA CONTINENTAL SIM2K-240 TC1767+TC1738

• KIA CONTINENTAL SIM2K-241 TC1767+TC17 38

• KIA KEFICO MEDG17.9.8 R5F72549R+TC1767

• KIA KEFICO MEG17.9.8 R5F72549R+TC1767

• LANDROVER BOSCH MED17.8.32 TC1793

• MAHINDRA BOSCH EDC17C53 TC1767

• MAZDA BOSCH DCU17PC DNX TC1766

• OPEL SIMTEC 81 29F400BT

• PEUGEOT BOSCH MEV17.4.2 TC1767

• RENAULT BOSCH EDC17CP58 TC1767

• RENAULT CONTINENTAL SID305 TC1766

• SEAT BOSCH MED17.1.61 TC1793S

• SKODA BOSCH MED17.1.61 TC1793S

• SKODA BOSCH MG1CS001 SPC5777

• SUZUKI BOSCH EDC17C69TC1793

• SUZUKI BOSCH ME17.9.64TC1724N

• VOLKSWAGEN BOSCH EDC17CP74 TC1793S

• VOLKSWAGEN BOSCH MG1CS001 SPC5777

Add Read/Write EXT flash, Read/Write EXT eeprom functions for below models:

• AUDI BOSCH ME7.1.1 ST10C167+AM29F800BB+95P08

• BENTLEY BOSCH ME7.1.1 ST10C167+AM29F800BB+95P08

• PORSCHE BOSCH ME7.1.1 ST10C167+AM29F800BB+95P08

• RENAULT BOSCH EDC15C13 ST10C167

• VOLKSWAGEN BOSCH ME7.1.1 ST10C167+AM29F800BB+95P08

Add Read/Write INT flash, Read/Write EXT flash, Read/Write EXT EEPROM functions for below models:

• AUDI BOSCH EDC16CP34 MPC563(4)

• AUDI BOSCH EDC16U31 MPC563(4)

• BENZ BOSCH EDC16CP36 MPC563(4)

• BMW BOSCH EDC16C31 MPC555(6)

• BMW BOSCH EDC16C31 MPC563(4)

• CHEVROLET BOSCH EDC16C37 MPC563(4)

• CHEVROLET BOSCH EDC16C9 MPC555(6)

• CHRYSLER BOSCH EDC16U31 MPC563(4)

• CITROEN BOSCH EDC16CP39 MPC563(4)

• DODGE BOSCH EDC16U31 MPC563(4)

• FIAT BOSCH EDC16C9 MPC555(6)

• FORD BOSCH EDC16CP39 MPC563(4)

• GMC BOSCH EDC16C37 MPC563(4)

• HOLDEN BOSCH EDC16C9 MPC555(6)

• JEEP BOSCH EDC16U31 MPC563(4)

• LANCIA BOSCH EDC16C9 MPC555(6)

• LANCIA BOSCH EDC16CP39 MPC563(4)

• LANDROVER BOSCH EDC16CP39 MPC563(4)

• MASERATI BOSCH ME9.1.1 MPC563(4)

• MITSUBISHI BOSCH EDC16CP39 MPC563(4)

• MITSUBISHI BOSCH EDC16U31 MPC563(4)

• NISSAN BOSCH EDC16C36 MPC563(4)

• NISSAN BOSCH EDC16CP33 MPC563(4)

• OPEL BOSCH EDC16C36 MPC563(4)

• OPEL BOSCH EDC16C9 MPC555(6)

• OPEL BOSCH EDC16CP33 MPC563(4)

• PEUGEOT BOSCH EDC16CP33 MPC563(4)

• PEUGEOT BOSCH EDC16CP39 MPC563(4)

• RENAULT BOSCH EDC16C36 MPC563(4)

• SAAB BOSCH EDC16C9 MPC555(6)

• SATURN BOSCH EDC16C9 MPC555(6)

• SEAT BOSCH EDC16U31 MPC563(4)

• SKODA BOSCH EDC16U31 MPC563(4)

• SUBARU BOSCH EDC16C9 MPC555(6)

• SUZUKI BOSCH EDC16C36 MPC563(4)

• TOYOTA BOSCH EDC16C10 MPC555(6)

• VAUXHALL BOSCH EDC16C36 MPC563(4)

• VAUXHALL BOSCH EDC16C9 MPC555(6)

• VOLKSWAGEN BOSCH EDC16CP34 MPC563(4)

• VOLKSWAGEN BOSCH EDC16U31 MPC563(4)

• VOLVO BOSCH EDC16C31 MPC555(6)

• VOLVO BOSCH EDC16C31 MPC563(4)

Add Read/Write INT flash, Read/Write EXT eeprom functions for below models:

• BAIC BOSCH ME7.8.8 ST10F275+95080

• CHEVROLET BOSCH ME7.9.9 KLINE ST10F275+95080

• CITROEN BOSCH ME7.4.5 ST1 OF275+95320(BOOT)

• DAEWOO BOSCH ME7.9.9 KLINE ST10F275+95080

• GM BOSCH ME7.9.9 KLINE ST10F275+95080

• GREATWALL BOSCH ME7.8.8 ST10F275+95080

• HOLDEN BOSCH ME7.9.9 KLINE ST10F275+95080

• OPEL BOSCH ME7.9.9 KLINE ST10F275+95080

• PEUGEOT BOSCH ME7.4.5 ST1 OF275+95320(BOOT)

• SUZUKI MAGNETI MARELLI 8DS CAN MPC5565+95640

Highlights Added

Add ECU INT eeprom data Conversion(CLONE) function for VOLKSWAGEN series MED17/EDC17 series.

Add IMMO OFF function for below models:

• VOLKSWAGEN MAGNETI MARELLI IAW 4HV 95320

• VOLKSWAGEN MAGNETI MARELLI IAW 7GV 95320

Details Optimized

Optimized software

OBDSTAR Update Greatwall Havel H5 2023 Proximity

 OBDSTAR X300 DP Plus and X300 Classic G3 released new Great Wall immo software.

Add proximity key programming function for

WEY GAOSHAN 2024

WEY TANK 400 2023-

Havel H5 2023

Havel MENGLONG 2023

Add all keys lost function for Greatwall Poer 2023- proximity

OBDSTAR DC706 Failed to Clone GM 6L80 TCM Solution

 Problem:

I acquired an obdstar dc706 and I want to clone a tcm 6L80 Chevrolet and I don't give communication I tried with 4 and can't any suggestions would be appreciated.

Feedback:

Updated. Voltage is the problem.

 I had low voltage use a fountain in 12 volts and the module came 10 check volts and done. Thanks.

How to Transfer OBDSTAR G3 Files from Tablet to PC?

 Sometimes you need to move memory files from your OBDSTAR X300 Classic G3 to a USB drive in order to change the data or de-clutter your files. Here is a tip on preparing the USB so the G3 can accept the files.



How to Transfer Files from OBDSTAR G3 Tablet to PC?



Preparing a USB Drive for Use With a OBDstar G3 Tool.

The procedure is similar to DC706.



NOTE:

It works best if properly formatted. The G3 tool seems a bit more fussy than the DC706 when it comes to the USB drive.

Format your U drive and creat a new folder for G3.

Insert a USB Disk into the USB port of the OBDSTAR G3 tablet.
Go to Home menu, press DP icon.

Go to Data Management->My Data->Local Data

Tick files you need to transfer
Long press files you need to transfer and press Copy

Paste Files to USB Disk G3 folder.

Successfully transfer file to U drive.

Done.

Clone Fiat 500 8GMK ECM with OBDSTAR DC706

 OBDSTAR DC706 software works perfectly on European Fiat 8GMK, 8GMW, 8GMF ect ECUs, tested many times.

Our customer did a Fiat 500 8GMK cloning the other week witout problem at all.

You can read, write and clone those ECUs on bench using P004/MP001.

Pinout Fiat 8GMK ECU

Select Fiat Magneti Marelli 8GMK CAN SPC564A80B4+ 95640

Connect

Read EXT EEPROM ok

Read INT flash ok

Write EXT eeprom ok

Write INT flash ok

NOTE: In North America, the ECMs might be same/similar as European/ROW versions but software is different. If DC706 failed to read US Fiat 8GMK/8GMW, send data log to OBDSTAR engineer.



FYI: You can clone those ECMs via P004/MP001 or even with godiag GPT adapter.

For example 8GMW works when connected with Godiag, or thru the pins on P004. You can use the godiag breakout harness instead of p004, it is much easier this way. It also has the 120ohm built in.

OBDSTAR DC706 Adds Hyundai Kia SIM2K240 SIM2K305 SIM2K241

 OBDSTAR DC706 released new TCU software version 30.25 on April 28th, 2024. Adds MEG17.9.8, GETRAG DC4, AQ250, AL750, AWF21 and more TCUs.



Highlights Added 8
Add Read/Write INT eeprom and Read/Write INT flash functions for below models:
• HYUNDAI/KIA KEFICO MEG17.9.8 TCM(R5F72549R) + ECM(TC1767)
• HYUNDAI/KIA KEFICO MEDG17.9.8 TCM(R5F72549R) + ECM(TC1767)
• HYUNDAI/KIA SIEMENS/CONTINENTAL SIM2K-240 TCM(TC1738)+ECM(TC1767) (BOOT)
• HYUNDAI/KIA SIEMENS/CONTINENTAL SIM2K-241 TCM(TC1738)+ECM(TC1767) (BOOT)
• HYUNDAI/KIA SIEMENS/CONTINENTAL SIM2K-305 TC1782 (BOOT)
• RENAULT GETRAG DC4 GEN2 TC1782
• SMART GETRAG DC4 GEN2 TC1782
• CHERY GETRAG DC4 GEN2 TC1782
• GEELY GETRAG DC4 GEN2 TC1782(BETA)

Add Read/Write EXT eeprom (95320), Read/Write INT flash(SH7058S) and Read ECU information functions for below models:
• MINI AISIN GA6F21WA SH7058S+95320
• GM AISIN AF40-6 SH7058S+95320
• OPEL AISIN AF40-6 SH7058S+95320
• SAAB AISIN AF40-6 SH7058S+95320

Add Read/Write EXT eeprom(95640), Read/Write INT flash(SH7058S) and Read ECU information functions for below models:
• VOLVO AISIN AWF21(7G9N/AG91/BJ32) SH7058S+95640
• LAND ROVERAISIN AWF21(7G9N/AG91/BJ32) SH7058S+95640
• FORD AISIN AWF21(7G9N/AG91/BJ32) SH7058S+95640
• AEOLUS AISIN TF-70SC SH7058S+95640

Add Read/Write EXT eeprom(95320), Read/Write INT flash(R4F7055F40) and Read ECU information functions for below models:
• VOLKSWAGEN AISIN AQ250 (09G) R4F7055F40+95320
• VOLKSWAGEN AISIN AL750 (09D) R4F7055F40+95320

Add Read/Write EXT eeprom(95320), Read/Write INT flash(R4F7058F) and Read ECU information functions for below models:
• VOLKSWAGEN AISIN AQ250 (09G) R4F7058F+95320
• VOLKSWAGEN AISIN AL750 (09D) R4F7058F+95320

Add Read/Write EXT eeprom(95640), Read/Write INT flash(SH7055S) and Read ECU information functions for below models:
• VOLVO AISIN AWF21(6G9N) SH7055S+95640
• LAND ROVER AISIN AWF21(6G9N) SH7055S+95640

Add Read/Write EXT eeprom(95320), Read/Write INT flash(SH7058) and Read ECU information functions for MINI AISIN GA6F21WA SH7058+95320.
Add Read/Write EXT eeprom(95320), Read/Write INT flash(SH7055) and Read ECU information functions for VOLVO AISIN AW55 SH7055+95320.
Add Read/Write INT flash(SH7058S) and Read ECU information functions for CHANGAN AISIN SH7058S.
Add Read/Write EXT flash function for GREATWALL SIEMENS/CONTINENTAL SIM2K-91 SAK-C167(AM29F400BB) (BOOT).
Add Repair data function for BENZ GETRAG VGS2-FDCT TC1784.

Details Optimized
Optimized BUICK/CHEVROLET GM 6T30 AM29BDD160G Connect function;
Optimized DQ381(0DE) Write INT flash function;
Optimized DQ200_G2, DQ200_G2_PQ Connect function.

OBDSTAR G3 Adds GM Proximity Programming till 2023

OBDSTAR X300 DP Plus and X300 Classic G3 released new GM immo software in April 2024.



Details Added
Add proximity key programming function for below models:
• CHEVROLET MONTANA 2023 South America
• CHEVROLET ONIX 2020-2023 South America
• CHEVROLET SPIN 2019-2023 South America
• BUICK ENCORE GX 2020-2024 USA-CANADA
• CADILLAC CT6 2023 USA-CANADA
• CADILLAC ESCALADE ESV 2023 USA-CANADA
• CADILLAC GT4 2023 USA-CANADA
• CADILLAC XT4 2024 USA-CANADA
• CADILLAC XT4 2020-2023 USA-CANADA
• CADILLAC XT5 2020-2023 USA-CANADA
• CADILLAC XT6 2020-2023 USA-CANADA
• CHEVROLET CAMARO 2020-2023 USA-CANADA
• CHEVROLET SILVERADO 2024 USA-CANADA
• CHEVROLET SILVERADO 1500 2024 USA-CANADA
• CHEVROLET SILVERADO 1500 2021-2023 USA-CANADA
• CHEVROLET SILVERADO 2500 2024 USA-CANADA
• CHEVROLET SILVERADO 3500 2024 USA-CANADA
• CHEVROLET TRAILBLAZER 2020-2023 USA-CANADA
• CHEVROLET TRAX/TRACKER 2023-2024 USA-CANADA
• GMC ACADIA 2020-2023 USA-CANADA
• GMC CANYON 2023 USA-CANADA
• GMC SIERRA 2024 USA-CANADA
• GMC SIERRA 1500 2024 USA-CANADA
• GMC SIERRA 1500 2021-2023 USA-CANADA
• GMC SIERRA 2500 2024 USA-CANADA
• GMC SIERRA 3500 2024 USA-CANADA
• GMC YUKON XL 2022-2023 USA-CANADA

Add blade key programming function for below models:
• CHEVROLET CRUZE 2020-2023 South America
• CHEVROLET ONIX 2020-2023 South America
• CHEVROLET PRISMA 2020-2023 South America
• CHEVROLET S10 2020-2023 South America
• CHEVROLET SPIN 2019-2023 South America
• CHEVROLET SILVERADO 1500 2021-2023 USA-CANADA
• CHEVROLET SILVERADO 3500 2017-2023 USA-CANADA
• CHEVROLET TRAILBLAZER 2020-2023 USA-CANADA
• GMC SAVANA 2022-2023 USA-CANADA
• GMC SIERRA 3500 2016-2023 USA-CANADA

Add remote control programming function for below models:
• CHEVROLET COLORADO
• CHEVROLET SILVERADO
• CHEVROLET SUBURBAN
• CHEVROLET TAHOE
• GMC CANYON
• GMC SIERRA
• GMC YUKON

OBDSTAR Adds Key Lexus NX RX 2022- Free Pin Code

 OBDSTAR X300 DP Plus and X300 Classic G3 adds Lexus 8A-B9 model

Add proximity key for following 8A-B9 models (add key free pin code)
Lexus Asia NX 2022-
Lexus Asia RX 2023-
Lexus Europe NX 2022-
Lexus Europe RX 2023-
Lexus Austiralia NX 2022-
Lexus Austiralia RX 2023-
Lexus US-Canada NX 2022-
Lexus US-Canada RX 2022-

Read and Write VW PCR 2.1 with OBDSTAR DC706 and MP001

How-to: read and write VW Continental Simos PCR 2.1 ECU with OBDSTAR DC706 and MP001 programmer.

You will need:

OBDSTAR DC706

OBDSTAR MP001 adapter and jumper cables

VW PCR2.1 ECU

Select VW Continental PCR 2.1 TC1796 ECU

Check instruction and wiring diagram

Connect ECU with DC706 and MP001

Select Bench mode with MP001

Connect ECU

Read and save EXT eeprom

Read and save INT flash

Write EXT eeprom, upload EXT eeprom need to write, Write EXT eeprom successfully.

Write INT flash, upload INT flash need to write, write INT flash successfully.

Read IMMO data

Read Pin code, CS and MAC

You can also Lock or Unlock ECU

www.obdii365.com

Tips to Read Chrysler GPEC2A with OBDSTAR DC706

 If you have some issues reading flash on Chrysler Jeep Dodge GPEC2A PCM using the OBDSTAR DC706 ECU cloning tool, here are the tips for GPEC2A.



Error 1: ECU not responding

Error 2:

made all connections as instructions say to do but only get ext eeprom read and all FFFFF in flash.

Tips for working on GPEC2A:



There is a power issue with these you have to supply additional power. DO NOT use the power adapter they provide to power the ECU, that is only for charging the tablet.



For BENCH & BOOT (workbench) operation, please use a reliable high-power DC regulated power supply (current not less than 5A) to power the ECU. OBDSTAR’s standard power adapter (current 2A) is only used for device charging and is not recommended for ECU. power supply, otherwise communication may fail due to low power of the power adapter!

You need to turn on the power to computer. Click Connect, then turn off power and turn back on fast. Then it will start writing to bootloader.







OBDSTAR DC706 made a change on how to connect. Look at the guide. Use the p004 now and have to jump 2 pins using a 1k ohm resistor.

www.obdii365.com
